General
- TypeDesktop
- FunctionCopy, print, fax, scan
- Print technologyLaser b/w
- Original formatmax A4 from platen glass
- Original feeder50 sheet A4 (standard, A6R-A4), 50-160 g/m² (with simultaneous duplex scanning)
- Print speed (A4, Simplex) B/W40 b/w-pages/min.
- Print speed (A4, Duplex) B/W20 b/w-pages/min.
- 1st page (printing, b/w)6.4 seconds
- Warm-up time17 seconds
- Copy resolution600 x 600 dpi
- Greyscales256
- Paper feed (Universal cassettes amount)1 x 250 sheet
- Paper feed (1st cassette types)A6R-A4
- Paper feed (Multi-Bypass amount)100 sheet multi-bypass (A6R-A3)
- Paper feed (Multi-Bypass types)A6R-A4, 216 × 356 mm -70 × 139.7 mm
- Paper weights (Universal cassette min)60 g/m²
- Paper weights (Universal cassette max)163 g/m²
- Paper weights (Multi-Bypass min)60 g/m²
- Paper weights (Multi-Bypass max)220 g/m²
- Paper weights (Duplex min)60 g/m²
- Paper weights (Duplex max)163 g/m²
- Paper output150 sheet A4
- System memory (RAM)512 GB
- System memory (RAM max)1536 GB
- Continuous copying (min)1
- Continuous copying (max)999
- Zoom (min)25 %
- Zoom (max)400 %
- Zoom (step)1 %
- Functionsduplex, job programs, job reservation, skip blank pages, quiet mode (half speed mode), N-up, continuous scan, ID card copy, 100 management codes
Dimensions / Weight
- Dimensions (height)437 mm
- Dimensions (width)417 mm
- Dimensions (depth)412 mm
- Weight19 kg
Environment
- Mains voltage220/240 V
- Utility frequency50/60 Hz
- Power consumption (max)990 W
- Power consumption (busy)661 W
- Power consumption (standby)21 W
- Power consumption (sleep)1 W
- Power consumption (TEC)0.54 kwh/week
- Noise level (busy, b/w)48.3 dB(A)
- Noise level (standby)undefined dB(A)
- SafetyGS/TÜV, CE
Printing system
- TypeIntegrated within the system
- Print formatA6R-A4
- Print resolution (min)max 600 x 600 dpi
- Print resolution (max)1,200 x 1,200 dpi
- ProcessorCortex-A9, 800 MHz
- Network protocolsTCP/IP, Net BEUI
- Operating systemsServer 2008 R2, Windows XP, Windows Vista, Windows 7, Windows 8, Server 2003, Windows 8.1, Windows 10, Server 2012 R2, Linux, Mac ex OS 10.5
- EmulationsPCL6 (PCL 5c, XL), KPDL 3 (PostScript 3 compatible), PRESCRIBE Ile, Line Printer, IBM Proprinter, Epson LQ-850, PDF 1.7, XPS, Open XPS
- FunctionsUSB direct printing, printing of e-mails, PDF direct printing, barcode printing, WSD-/Internet printing, Mobile Print (Android, iOS)/Apple AirPrint, Apple AirPrint, Wi-Fi Direct®, Google Cloud Print
Scanning system
- Scan typeCIS colour and b/w
- Scan formatmax A4
- Scan speed (Feeder 1, simplex, colour)23 DIN-A4-image pages/min. in 300 dpi
- Scan speed (Feeder 1, simplex, b/w)40 DIN-A4-image pages/min. in 300 dpi
- Scan speed (Feeder 1, duplex, colour)16 DIN-A4-image pages/min. in 300 dpi
- Scan speed (Feeder 1, duplex, b/w)32 DIN-A4-image pages/min. in 300 dpi
- Scan resolution600 dpi
- Scan modephoto/text, Photo, optimised for OCR, text
- File typesTIFF, JPEG, PDF, high compression PDF, PDF/A-1, XPS
- Interfaces10/100BaseTX, USB 2.0
- Network protocolTCP/IP
- Operating systemsWindows XP, Windows Vista, Windows 7, Windows 8, Windows 8.1, Windows 10, Server 2003, Server 2008, Server 2012 R2, Linux, Mac ex OS 10.5
- FunctionsScan to SMB, scan to e-mail, scan to FTP, scan to USB, TWAIN scan, WIA scan, SMTP authentication, LDAP
Fax system
- TypeIntegrated within the system
- CompatibilitySuper G3
- Original formatmax A4
- Modem speed33.6 kbps
- Transmission speed3 seconds or less using JBIG
- Compression methodMH, MR, JBIG, MMR
- Fax resolutionStandard (200 x 100 dpi), fine (200 x 200 dpi), super fine (200 x 400 dpi), ultra fine (400 x 400 dpi)
- Fax memory (image)3.5 MB
- Abbreviated dial200 numbers
- One touch dial22 numbers
- Group dial50 numbers
- Operating systemsWindows XP, Windows Vista, Windows 7, Windows 8, Windows 8.1, Windows 10, Server 2003, Server 2008 R2, Server 2012 R2
- Functionsdelayed transmission, automatic redialling, Network fax driver
Options
- Paper feedmax 2 x PF-1100 (250 sheet universal cassettes [A6R-A4, 60-163 g/m²])
- Other optionsUG-33 ThinPrint® kit, Card authentication kit (B), cabinet no. 78
