General
- TypeDesktop
- FunctionCopy, print, scan
- Print technologyLaser b/w
- Original formatmax A4 from platen glass
- Original feeder75 sheet document processor with automatic reverse function, A6R-A4, 50-120 g/m² (standard)
- Print speed (A4, Simplex) B/W45 b/w-pages/min.
- Copy speed (A4, Simplex) B/W45 b/w-pages/min.
- Print speed (A4, Duplex) B/W22.5 b/w-pages/min.
- Copy speed (A4, Duplex) B/W22.5 b/w-pages/min.
- 1st page (printing, b/w)5.3 seconds
- 1st page (copying, b/w)6 seconds
- Warm-up time23 seconds
- Copy resolution600 x 600 dpi
- Greyscales256
- Paper feed (Universal cassettes amount)1 x 500 sheet
- Paper feed (1st cassette types)A5R-A4
- Paper feed (Multi-Bypass amount)100 sheet multi-bypass (A6R-A3)
- Paper feed (Multi-Bypass types)A6R-A4 [min 70 x 148 mm, max 216 x 356 mm]
- Paper weights (Universal cassette min)60 g/m²
- Paper weights (Universal cassette max)120 g/m²
- Paper weights (Multi-Bypass min)60 g/m²
- Paper weights (Multi-Bypass max)220 g/m²
- Paper weights (Duplex min)60 g/m²
- Paper weights (Duplex max)120 g/m²
- Paper output250 sheet A4 (face-down)
- System memory (RAM)1.5 GB
- System memory (RAM max)3.5 GB
- Continuous copying (min)1
- Continuous copying (max)999
- Zoom (min)25 %
- Zoom (max)400 %
- Zoom (step)1 %
- FunctionsColour touch screen (7 inch), duplex, job reservation, ID card copy, Scan once - Copy Many, continuous scan, skip blank pages, N-up, quiet mode (half speed mode), 100 management codes, secure boot and run time integrity check
Dimensions / Weight
- Dimensions (height)575 mm
- Dimensions (width)475 mm
- Dimensions (depth)476 mm
- Weight22.5 kg
Environment
- Mains voltage220/240 V
- Utility frequency50/60 Hz
- Power consumption (max)1270 W
- Power consumption (busy)599 W
- Power consumption (standby)57 W
- Power consumption (sleep)0.5 W
- Power consumption (TEC)0.62 kwh/week
- Noise level (busy, b/w)52 dB(A)
- Noise level (standby)22 dB(A)
- SafetyCE, GS/TÜV
Printing system
- TypeIntegrated within the system
- Print formatA6R-A4
- Print resolution (max)1,200 x 1,200 dpi
- ProcessorARM Cortex-A53 Dual Core, 1,4 GHz
- InterfacesUSB 2.0, 10/100/1000BaseTX, USB host
- Network protocolsTCP/IP, Net BEUI
- Operating systemsWindows 8, Windows 8.1, Windows 10, Server 2012, Server 2012 R2, Server 2016, Server 2019, Linux, Server 2022, Chrome OS, Mac ab OS 10.14
- EmulationsPCL6 (PCL 5e/c, XL), KPDL 3 (PostScript 3 compatible), PRESCRIBE Ile, Line Printer, IBM Proprinter, Epson LQ-850, XPS, Open XPS, PDF 1.7
- FunctionsUSB direct printing, printing of e-mails, PDF direct printing, private printing, barcode printing, WSD-/Internet printing, Mobile Print (Android, iOS)/Apple AirPrint, Google Cloud Print, Wi-Fi, Apple AirPrint, Mobile Print (Android/iOS), Microsoft Universal Print
Scanning system
- Scan typeCCD colour and b/w
- Scan formatmax A4
- Scan speed (Feeder 1, simplex, colour)40 DIN-A4-image pages/min. in 300 dpi
- Scan speed (Feeder 1, simplex, b/w)60 DIN-A4-image pages/min. in 300 dpi
- Scan speed (Feeder 1, duplex, colour)17 DIN-A4-image pages/min. in 300 dpi
- Scan speed (Feeder 1, duplex, b/w)26 DIN-A4-image pages/min. in 300 dpi
- Scan resolution200 dpi, 300 dpi, 400 dpi, 600 dpi
- Scan modePhoto, text, photo/text, optimised for OCR
- File typesTIFF, JPEG, PDF, PDF/A-1a, PDF/A, PDF/A-1b, PDF/A-2a, PDF/A-2b, PDF/A-2u, high compression PDF, encrypted PDF, XPS, OpenXPS, MS Office/text-searchable PDF
- Interfaces10/100/1000BaseTX, USB 2.0
- Network protocolTCP/IP
- Operating systemsWindows 8, Windows 8.1, Windows 10, Server 2012, Server 2016, Server 2012 R2
- FunctionsScan to SMB, scan to e-mail, scan to FTP, scan to USB, TWAIN scan, WIA scan, SMTP authentication, LDAP, Multi Crop Belegscan
Options
- Paper feedmax 4 x PF-3110 (500 sheet universal cassettes (A5R-A4, 60-120 g/m²])
- Other optionsScan extension kit (A), Card authentication kit (B), Card reader holder (10), UG-33 ThinPrint® kit, IB-50 Gigabit Ethernet card, cabinet no. 79 (high), cabinet no. 80 (low), HD-18 SSD (256 GB), IB-37 WLAN card (IEEE802.11a/b/g/n/ac), HD-17 SSD (64 GB), caster kit CA-3100, IB-51 WLAN card, IB-38 W-LAN card**** (IEEE802.11 b/g/n Wi-Fi direct), HD-19 SSD (512 GB), UG-50 Trusted Platform Modul
