P-C2480i MFP

Space saving and efficient, well equipped and easy to use - this is how the P-C2480i MFP, which delivers 24 A4 pages/min, is most aptly described. Its HyPAS interface makes the integration of individual software solutions possible which will support you in digitising your documents most easily. But this is not all! Also the hardware can be upgraded whenever the need arises, for instance with additional paper supply or a hard disk.
Find a Retailer
P-C2480i MFP Bild 1 von 5
1 / 5

General

  • TypeDesktop
  • FunctionCopy, print, scan, optional: fax
  • Print technologyLaser colour and b/w
  • Original formatmax A3 from platen glass
  • Original feeder50 sheet A4 (standard), min 140 x 182 mm, max 297 x 432 mm, 45-160 g/m² (simplex), 50-120 g/m² (duplex)
  • Copy resolution600 x 600 dpi
  • Greyscales256
  • Paper feed (Universal cassettes amount)1 x 500 sheet, 1 x 500 sheet
  • Paper feed (1st cassette types)A5R-A3
  • Paper feed (Multi-Bypass amount)100 sheet multi-bypass (A6R-A3)
  • Paper feed (Multi-Bypass types)A6R-A3
  • Paper output250 sheet A4
  • Job Separator30 sheet A4 (standard)
  • System memory (Optional)32/128 GB SSD
  • FunctionsColour touch screen (4.3 inch), duplex, Print from/Scan to USB Stick, job reservation, N-up, favourites, 100 management codes, etc.
  • Print speed (A4, Simplex) B/W24.0 b/w-pages/min.
  • Print speed (A3, Simplex) B/W12.0 b/w-pages/min.
  • Copy speed (A4, Simplex) B/W24.0 b/w-pages/min.
  • Copy speed (A3, Simplex) B/W12.0 b/w-pages/min.
  • Print speed (A4, Simplex) Colour24.0 colour pages/min
  • Print speed (A3, Simplex) Colour12.0 colour pages/min
  • Copy speed (A4, Simplex) Colour24.0 colour pages/min
  • Copy speed (A3, Simplex) Colour12.0 colour pages/min
  • 1st page (printing, colour)10.2 seconds
  • 1st page (printing, b/w)7.5 seconds
  • 1st page (copying, colour)9.8 seconds
  • 1st page (copying, b/w)7.6 seconds
  • Paper weights (Universal cassette min)60.0 g/m²
  • Paper weights (Universal cassette max)256.0 g/m²
  • Paper weights (Multi-Bypass min)60.0 g/m²
  • Paper weights (Multi-Bypass max)256.0 g/m²
  • Paper weights (Duplex min)60.0 g/m²
  • Paper weights (Duplex max)220.0 g/m²
  • System memory (RAM)1.5 GB
  • System memory (RAM max)3.0 GB
  • Continuous copying (min)1.0
  • Continuous copying (max)999.0
  • Zoom (min)25.0 %
  • Zoom (max)400.0 %
  • Zoom (step)1.0 %

Dimensions / Weight

  • Dimensions (height)753.0 mm
  • Dimensions (width)590.0 mm
  • Dimensions (depth)590.0 mm

Environment

  • Noise level (busy, b/w)47.3 dB(A)
  • Noise level (busy, colour)48.3 dB(A)
  • Noise level (standby)30.8 dB(A)
  • Mains voltage220/240 V
  • SafetyGS/TÜV, CE
  • Utility frequency50 Hz
  • Power consumption (busy)550.0 W
  • Power consumption (max)850.0 W
  • Power consumption (TEC)0.31 kwh/week
  • Power consumption (standby)70.0 W
  • Power consumption (sleep)0.5 W

Printing system

  • Print resolution (max)1,200 x 1,200 dpi (reduced speed)
  • Print resolution (min)600 x 600 dpi
  • EmulationsPCL6 (PCL 5c, XL), KPDL 3 (PostScript 3 compatible), PRESCRIBE Ilc, PDF 1.7, XPS
  • Functions200 dpi, USB direct printing, PDF/XPS direct printing, printing of e-mails, private printing, barcode printing, Mobile Print (Android/iOS), Apple AirPrint, Mopria, Google Cloud Print, Wi-Fi
  • Operating systemsWindows 7, Windows 8, Windows 8.1, Windows 10, Server 2008 R2, Server 2012 R2, Server 2016, Novell NetWare, Linux, Mac ex OS 10.5, Mac ex OS 10.5
  • TypeIntegrated within the system
  • ProcessorARM Cortex-A9 Dual core 1.2 GHz
  • InterfacesUSB 2.0, 10/100/1000BaseTX, USB host (2), NFC, Wi-Fi
  • Print formatA6R-A3
  • Network protocolsTCP/IP, Net BEUI

Scanning system

  • Scan speed (Feeder 1, duplex, b/w)16.0 DIN-A4-image pages/min. in 300 dpi
  • Scan speed (Feeder 1, simplex, b/w)50.0 DIN-A4-image pages/min. in 300 dpi
  • Scan speed (Feeder 1, duplex, colour)16.0 DIN-A4-image pages/min. in 300 dpi
  • Scan speed (Feeder 1, simplex, colour)50.0 DIN-A4-image pages/min. in 300 dpi
  • Scan formatmax A3
  • File typesTIFF, PDF, XPS, OpenXPS, high compression PDF, JPEG
  • Interfaces10/100/1000BaseTX, USB 2.0
  • Network protocolTCP/IP
  • Operating systemsWindows 7, Windows 8, Windows 8.1, Windows 10, Server 2008 R2, Server 2012 R2, Server 2016
  • Scan modePhoto, text, photo/text, optimised for OCR
  • FunctionsScan to SMB, scan to e-mail, scan to FTP, scan to USB, TWAIN scan, WIA scan, SMTP authentication, LDAP
  • Scan typeCIS colour and b/w
  • Scan resolution200 dpi, 300 dpi, 400 dpi, 600 dpi

Fax system

  • One touch dial100.0 numbers
  • Group dial50.0 numbers
  • Modem speed33.6 kbps
  • Abbreviated dial200.0 numbers
  • Fax memory16.0 MB
  • Fax memory (image)12.0 MB
  • CompatibilitySuper G3
  • Transmission speed3 seconds or less using JBIG
  • FunctionsNetwork fax driver, automatic redialling, delayed transmission
  • Typeoptional Fax System 13
  • Operating systemsWindows 7, Windows 8, Windows 8.1, Windows 10, Server 2008 R2, Server 2012 R2, Server 2016
  • Compression methodJBIG, MMR, MR, MH
  • Original formatmax A3
  • Fax resolutionStandard (200 x 100 dpi), fine (200 x 200 dpi), super fine (200 x 400 dpi), ultra fine (400 x 400 dpi)

Options

  • Other optionsData security kit (E), Data security kit (E), Scan extension kit (A), Card authentication kit (B), UG-33 ThinPrint® kit, IB-50 Gigabit Ethernet card, IB-36 or IB-51 WLAN card, HD-6 SSD (32 GB), HD-7 SSD (128 GB), cabinet no. 62
  • Paper feedPF-470 (1 x 500 sheet universal cassettes (A5R-A3)), PF-471 (2 x 500 sheet universal cassettes (A5R-A3))

Notes on technical data

  1. DIN/ISO 7779/9296↩
  2. depending on the operating status↩
  3. depending on the operating status↩
  4. depending on the operating status↩
  5. depending on the operating status↩
  6. DIN/ISO 7779/9296↩
  7. DIN/ISO 7779/9296↩
  8. optional↩
  9. optional↩
  10. optional↩
  11. optional↩
  12. When using HD-6 or HD-7, the Data Security Kit can be activated free of charge.↩
  13. When using HD-6 or HD-7, the Data Security Kit can be activated free of charge.↩
  14. additional memory required for full functionality↩
